RS PRO, 25 Pole D-sub Connector, Female Interface Module, DIN Rail Mount

RS Stock No.:
0425112
Brand:
RS PRO

Technical Reference


Legislation and Compliance

RoHS Status: Not Applicable

Statement of Conformity

RS Components
Statement of Conformity

This statement confirms that the product detailed below complies with the specifications currently published in the RS media and has been subject to the strict quality conditions imposed by RS Components’ internal management systems. Furthermore and where applicable, it confirms that all relevant semiconductor devices have been handled and packed under conditions that meet the administrative and technical requirements of ANSI/ESD S20.20 and EN61340-5-1 electrostatics control standards.

Compliant Product Details
RS stock number 0425112
Product description RS PRO, 25 Pole D-sub Connector, Female Interface Module, DIN Rail Mount
Manufacturer / Brand RS PRO

The foregoing information relates to product sold on, or after, the date shown below.

RS COMPONENTS

Date Jun 13, 2024

RS Components Pte Ltd Robinson Road, P.O. Box 1582, Singapore 903132

Country of Origin: PL


Product Details


Specifications

Attribute Value
Brand RS PRO
Connector Type D-sub
Depth 62 mm
Length 90 mm
Number of Contacts 25
Width 70 mm
Dimensions 90 x 70 x 62 mm
Minimum Operating Temperature -20 °C
Voltage Rating 50 V
Maximum Operating Temperature +50 °C
Current Rating 1 A
Gender Female
Mounting Type DIN Rail Mount
Cable CSA 4 mm²
Checking stock...
VND
2,031,777.44
Out of stock
Price Each
Unit(s)Per Unit(VND)
12,031,777.44
*price per unit indicative
